New

Lumination® LRXG

Commercial retrofit & new construction 6” round downlight with 360° rotation & 35° tilt. Three-level selectable colors available. Family look with LRX series.

Daintree EnergyStar ProLine QuickShip cULus 5 Year Warranty Damp Rated Dimmable Selectable CCT RoHS

Features & Benefits

  • Daintree® Wireless Controls options for code compliance and additional energy savings
  • Ease of installation with one-piece tool-less fixture
  • Below-ceiling access for convenient maintenance
  • Field Selectable Color Temperatures
  • Selectable Warm 2700/3000/3500K & Selectable Cool 3500/4000/5000K
  • Easy adjustability & rotation to create stunning accent and wall washing ambiance

Specifications

Product Technology
Daintree®
Family Modules/Configurations
6in, Round, Adjustable
Voltage Offering
120-277V
Lumen Range
1,525 - 2,000lm
CCT Offering
Field Selectable, 2700K, 3500K, 4000K, 5000K
CRI Offering
80, 90 MTO
Mounting Options
Recessed
Wattage Range
20 W
Efficacy Range
76 - 92 LPW
Color Offering
White
Optics & Distributions
High efficiency reflector and optical diffuser, Medium Distribution, Wide Flood, 360° Rotation, 35° Tilt
Controls & Sensors
0-10V Dimming, Daintree Wireless Enabled
Certifications
UL, cUL, ENERGY STAR, FCC
Ratings
RoHS, IP30, Damp, Dry
Operating Temp
-10 to 40 °C
Lumen Maintenance Rating
L85 @ 60,000 hours
Warranty
5 year limited warranty
Woman on ladder adjusting light fixture

Field Adjustable

Easy adjustability of 360° rotation and 35° tilt creates stunning accent and wall washing ambiance lighting layers for commercial and retail new construction and retrofit commercial downlight applications. When this round downlight is placed in the fixed (0°) position, it performs as a standard downlight, and compliments the LRX family.

Intelligent Controls

Daintree® Wireless Controls provide out-of-the-box integration for enhanced functionality and energy savings. Daintree Wireless Controls provides additional energy savings and the infrastructure to grow into the world of IoT today, or in the future.

Office with lines showing connections for intelligent controls
Man on ladder cutting round ceiling hole

Designed with Installers in Mind

This ideal one-piece, tool-less retrofit downlight converts most existing traditional downlights with an easy installation of clamping onto existing rough-in frames. New construction applications utilize a new matching frame-in kit, containing a PSU box and adjustable butterfly brackets that work with your existing materials or the accessory hanger bars option.
