Evolve® ERLC

The Evolve ERLC series Cobra Head is a 30% lighter compact fixture with advanced reflective optics optimized for residential and local roadway solutions.
DLC Standard cULus Assembled in USA BAA IDA IK Rated IP Rated Controls Enabled Wet Rated

Features & Benefits

  • Advanced Reflector Optic design optimizes application efficiency, minimizes glare and provides superior cut off with significantly less wasted light
  • Excellent light control which aims light directly on primary target, optimizing watts
  • Flat, tempered glass lens is less prone to dirt accumulation resulting in < 1% LDD per year over 10 years
  • Controls ready design: All Cobraheads have a standard ANSI 7 pin PE Receptacle
  • Designed and manufactured in the USA
  • Offerings to 7,000 Lumens with up to 143 LPW
Utility Rebates
Where To Buy
SPEC SHEET

Specifications

Voltage Offering
120-277V
Lumen Range
1,760 - 7,000lm
CCT Offering
2700K, 3000K, 4000K, 5000K
CRI Offering
70
Mounting Options
Adjustable for 1.25 to 2.0 in. nominal mounting pipe, 4 Bolt Slipfitter (option)
Wattage Range
15 - 56 W
Efficacy Range
110 - 143 LPW
Color Offering
Gray, Black, Dark Bronze, White, RAL and custom colors available
Optics & Distributions
Type II Narrow, Type II/Type III, Type III, Type V
Controls & Sensors
0-10V Dimming, 7-pin PE Receptacle, LightGrid™ Compatible, LL PE available (option)
Certifications
UL, cUL, IDA, DLC Standard, FCC
Ratings
RoHS, IK, Wet, BAA
Operating Temp
-40 to 50 °C
Lumen Maintenance Rating
L93 @ 60,000 hours
Warranty
5 year limited warranty, 10 year optional warranty

Product Documents

ERLC-Reflective-Optics-View

Custom Engineered Reflective Optic Technology

Optimizes application efficiency, minimizes driver glare, and 'shapes' the light to put the light where it is needed.

Designed and Assembled in The USA

The entire Current Roadway street light portfolio is designed and assembled by our industry leading team in our state of the art manufacturing center in Hendersonville, NC.

LightGrid™ Compatible

Current's entire Roadway products portfolio is compatible with LightGrid. LightGrid allows municipalities and transportation departments the ability to remotely monitor energy consumption, detect failures, dim fixtures remotely and achieve real time energy metering.

Application Photos

LED Street Lighting
