Evolve® ECLP

The ECLP offers energy efficiency and quality of light in a sleek low-profile look. Suitable for wet locations, optimized for open canopy applications.
Daintree Wireless Lighting Controls Icon DLC Standard cULus UL 5 Year Warranty Assembled in USA BAA IP Rated Title 24 RoHS

Features & Benefits

  • Daintree® Wireless Controls options for code compliance and additional energy savings
  • Flat glass lens with optimized reflective optics
  • Extremely light weight at 12lbs. easy to handle during installation
  • 1.5G vibration rated die cast housing
  • Designed for open ceiling canopy and suitable for wet locations
Utility Rebates
Where To Buy
SPEC SHEET

Specifications

Product Technology
Daintree®
Voltage Offering
120-277V, 347-480V
Lumen Range
3,700 - 13,400lm
CCT Offering
3000K, 4000K, 5000K
CRI Offering
70
Mounting Options
Surface
Wattage Range
29 - 101 W
Efficacy Range
119 - 138 LPW
Color Offering
White, Black, Dark Bronze
Optics & Distributions
Type V
Controls & Sensors
Integral Sensor, Daintree Integral Sensor
Certifications
UL, cUL, Title 24, DLC Standard, FCC
Ratings
RoHS, IP65, Wet, BAA
Operating Temp
-40 to 40 °C
Lumen Maintenance Rating
L91 @ 60,000 hours
Warranty
5 year limited warranty

Product Documents

Office with lines showing connections for intelligent controls

Intelligent Controls

Daintree Wireless Controls provide out-of-the-box integration with for enhanced functionality and energy savings. Daintree Wireless Controls provides additional energy savings and the infrastructure to grow into the world of IoT today, or in the future.

Robust Mechanical Design

Fixtures are designed with scalable lumen levels. Vibration testing is performed in accordance with industry standards with fully sealed optical enclosures. 6kV/3kA surge is minimum in all ECLP fixtures.

Man on ladder cutting round ceiling hole

Designed with Installers in Mind

The ECLP is designed to be extremely light weight, which makes handling and installation a breeze.

DLC qualified models available. Please refer to http://www.designlights.org/QPL for complete information.
