Lumination® LBT

LBT combines advanced LED technology with long life and better lumen depreciation ratings. The thin frame gives the unique appearance of a “lit” ceiling tile.
5_Yr_Warranty_Icon Title_24_Compliant_Icon Title_20_Compliant_Icon TAA_Compliant_Icon RoHS_Icon Dimmable_Icon Damp_Rated_Icon Daintree_Icon cULus_Icon Controls_Enabled_Icon

Features & Benefits

  • Daintree® Wireless Controls options for code compliance and additional energy savings
  • Uniform light distribution across the entire face of the luminaire with no hotspots, pixilation or banding
  • Evenly fills the entire T-grid space for a frameless appearance - uniquely looks like a lit ceiling tile
  • Thin 3.5" profile allows for utilization in spaces with a shallow plenum
  • EMBB test switch mounted remotely or next to fixture in ceiling
Utility Rebates
Where To Buy
SPEC SHEET

Specifications

Product Technology
Daintree®
Family Modules/Configurations
2x2, 2x4, 1x4
Voltage Offering
120-277 V, 347 V
Lumen Range
1,500 - 7,200lm
CCT Offering
3500 K, 4000 K, 5000 K
CRI Offering
80
Mounting Options
Recessed, Surface Mount, Ceiling Mount
Wattage Range
13 - 56 W
Efficacy Range
114 - 133 LPW
Color Offering
White
Optics & Distributions
Medium Lambertian
Controls & Sensors
0-10V Dimming, Daintree Wireless Enabled
Certifications
cULus, FCC
Ratings
Damp, TAA, RoHS
Operating Temp
-20 to 35 °C
Lumen Maintenance Rating
L85 @ 50,000 hours
Warranty
5 year limited warranty

Product Documents

Attractive Aesthetic

LBT offers a highly unique panel look and design. While almost every panel light has a pronounced frame, the LBT frame is minimized to “hide” behind the 15/16” T-grid. This gives the appearance of a ceiling tile that fills the entire grid, only it is lit. This, combined with the L85@50,000 hour life rating for the entire luminaire and a 10 year, 100,000 hour driver component design put LBT in a class of it’s own when it comes to panels.

Smooth, Uniform Light

The mantra of “smooth, uniform light” has been part of our DNA since the beginning. This is “not your father’s fluorescent fixture” modified for LED’s. Engineered for LED’s with LED’s from the ground up with the fixture structure, paint and LED technology to maximize the proper use of light. Considering diffuser transmissivity, LED pitch and depth to create uniform light across the diffuser, pixels and strips of light will never be seen.

Reliability You Can Count On

Our Engineering team prioritizes quality and reliability as #1. Heartbeat components like LEDs and drivers, are the key focus for design and validation. You will have peace of mind that a job with Current fixtures designed for total cost of ownership over the lifetime are used. With drivers designed with 10 year, 100,000 hour components, you can expect a B0 failure rate (designed for zero failures at ten years) for these luminaires.
