Daintree® WAC60

The WAC60 Wireless Area Controller is the heart of the Daintree Networked platform. It communicates with Daintree Networked devices across a distributed network.
Daintree Wireless Lighting Controls Icon DLC Standard ioXt logo

Features & Benefits

  • WAC60 is the next-generation hardware heart of Daintree Networked wireless controls solution for smart buildings
  • An embedded networked device that manages wireless communications for switches, sensors, ballasts/drivers, thermostats, and other end-points
  • WAC collapses complex control panels, gateways, and miles of wires into a single powerful controller
  • Control the entire building envelope with one controls system, including indoor, outdoor and highbay lighting
  • Integrate with HVAC or other Building Automated Systems (BAS)
  • Real time analytics and programming with Daintree Controls Software
  • A WAC can independently control an area, and multiple WACs can network to scale the system to thousands of lights, sensors, and building control devices across a distributed network
  • IoXt Certified. IoXt is the Global Standard for IoT Security®
Utility Rebates
Where To Buy
SPEC SHEET

Specifications

Controls Platform
Daintree Networked
Power Supply
12V DC, 0.9A (max), 3.4W (network joined), 2 options: PoE (with addition of a PoE splitter, optional not included) and via a wall plug-in power supply (included)
Input Voltage
12VDC 0.9A (max)
Memory & Storage
2 GB RAM, 8 GB Flash
Radio Properties
2.4GHz ISM Band, 100mW (+20dBm)
I/O
(2) 10/100 Mbps Ethernet, (2) USB Type A (host), (1) microSD memory card, (1) 2.1mm barrel (power), (2) Button (configuration), (1) Modbus/RS485 (via USB interface)
Connectivity Protocol
RS-485 (via USB/RS-485 adapter), Ethernet, IEEE 802.15.4 (through the Daintree WAC software)
LED Status Indicators
Green LED: Normal Operation, Orange LED: Attention Required, Red LED: Error Condition
Operating Temp
0 to 40 °C
Length
1.2 In
Width
8.0 In
Height
9.4 In
Weight
1.06 Lb
Certifications
ioXt, UL, CE, DLC Standard, FCC
Ratings
Dry
Warranty
5 year limited warranty

Product Documents

Brochures / Catalogs

Whitepapers / Infographics

Installation Guides

Warranties

Daintree Networked System Architecture How it works infographic

WAC60 is the Heart of the Daintree Networked Wireless Controls System

The Wireless Area Controller (WAC60) is designed to deliver intelligent local control across a large area for hundreds of interoperable wireless sensors and control devices from Daintree ecosystem partners. Control the entire building envelope with one controls system, including indoor, outdoor and highbay lighting. Integrate with HVAC or other Building Automated Systems (BAS).

Daintree Networked

Daintree Networked provides the infrastructure for feature-rich commercial lighting control for LED lighting. The Daintree Networked system also allows interconnectivity with other systems like HVAC, Plug Load control, fans, water heaters, air compressors and refrigeration units. The Daintree Networked platform allows building owners and managers the ability to monitor and resolve energy performance with the Daintree apps. Daintree Networked allows customers to go beyond lighting control and into the world of IoT.

Daintree Networked multi-site graphic
Young man at computer using Daintree Controls Software (DCS) to program Daintree Wireless Controls

Flexible Scheduling and Dimming Lighting Control

The Daintree Networked platform allows building owners and managers the ability to monitor and resolve energy performance with the Daintree apps. Daintree Networked allows customers to go beyond lighting control and into the world of IoT.
